MIL-DTL-62267B(AT)
TABLE I. Smoke grenade discharger firing pin voltage.
Firing
Left side discharger
Right side discharger
pushbutton
firing pins
firing pins
Voltage
Right
1, 2, 5
3, 4, 6
Vehicle (ref 3.6)
0 ± 0.5 Vdc
Right
3, 4, 6
1, 2, 5
Left
3, 4, 6
1, 2, 5
Vehicle (ref 3.6)
Left
1, 2, 5
3, 4, 6
0 + 0.5 Vdc
3.4.22 Vibration and noise level. Equipment operation shall not exceed the maximum
acceptable noise level specified in table II (see 4.5.4.22).
TABLE II. Maximum acceptable noise levels for Army material
command equipment (continuous noise).
Octave band center
Maximum acceptable noise level
frequency
(dB ref. 0.0002 microbar)
63
121
125
111
250
103
500
102
1000
100
2000
100
4000
100
8000
100
3.5 Stowed equipment. The chassis shall be capable of stowing all on-vehicle equipment
(OVE) items in the spaces provided (see 4.5.2).
3.6 Electrical system. The chassis electrical system shall consist of the hull electrical
subsystem as described below. System shall be 24 volts direct current (Vdc), nominal (see 4.5.2).
3.6.1 Power plant electrical. The power plant electrical equipment shall consist of the
following: sending units necessary to provide engine data in the form of electrical signals to the
operator's instrument panel, an engine electrical disconnect to facilitate engine removal and
replacement, an electrical starter motor capable of starting the engine, and an air-cooled generator
(see 4.5.2).
3.6.2 Interior lighting. Each crew position shall contain a domelight to provide general
illumination when required. The domelight shall contain provisions for adjusting light intensity
and red filter for night vision adaption (see 4.5.2).
3.6.3 Auxiliary outlet. One outlet (24 Vdc nominal) shall be provided in the hull to mate
with the OVE trouble light assembly. The auxiliary outlet circuit shall be protected with a
15 ampere, automatic reset, circuit breaker (see 4.5.2).
9
