MIL-DTL-45360H(AT)

0.625 DIA 4

Holes See Note 2

14 DIA

15 DIA

14.5 15

0.5 7.5

0.5

7.5

14.5

NOTES:

1. Material, wire cloth, plain weave, 4x4 mesh, 0.0348 diameter per ANSI/AWCI01

and ASTM E437.

2. Holes may be formed with drift pin at installation.

3. Dimensions are in inches.

FIGURE 2. Screen.
