MIL-DTL-45360H(AT)
6.7  Changes from previous issue. Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
Clamp 2 Required
See Note 1
See Note 3
4
5.5 Diameter
Detail A See Note 2
1
Detail A-1 Required
NOTES:
1. Flexible hose to be made from material conforming to A-A-52546 or equivalent.
2. Plug to be made from 1 inch plywood, A-A-55057, type a, std. int. with ext. glue.
3. Use clamp, hose, low pressure type "F" with diameter range 4.125 and 7 inches.
FIGURE 1. Boot, air restrictor.
26
