MIL-DTL-45360H(AT)
12 Lag Screw
12 Washers, flat (zinc plated), inside
diameter 0.43 inch, outside
diameter 2 inches, thickness 0.83 inch.
Item 4
Item 2
Item 4
Item 6
Item 3
Item 1
Nailing as required
Item 3
16 - Bolts, 0.375 inch nominal, 16 UNC-2A, 3.25 inches
Item 5
long, square neck, round head, zinc-plated.
16 - Washers, flat (zinc plated), inside diameter 0.438,
outside diameter 2 inches, thickness 0.83 inch.
16 - Nuts, plain, square steel, zinc plated, nominal thread
size 0.375-16.
SHEET 1 OF 3
NOTES:
1. See figures 5a and 5b for details of items 1 through 6.
2. Dimensions are in inches.
3. Tolerance unless otherwise specified + 1/16.
FIGURE 5. Saddle BII stowage.
