MIL-C-45360 Carriers, Personnel, Full-Tracked, Armored: M113A2, And M113A3: Mortars, Self-Propelled:M106A2 \(107Mm\), M125A2 \(81Mm\) And M1064, M1064A3 \(120Mm\); Smoke Generators: M1059, M1059A3 And M58; Processing For Storage And Shipment OfThis specification covers the processing for storage and shipment of the M113A2 and M113A3 Armored, Full-Tracked, Personnel Carriers; the 107mm, M106A2, and 81mm, M125A2, and 120mm, M1064, M106A3 Self-Propelled Mortars; and the M1059, M1059A3 and M58 Smoke Generators \(see 1.2 and 6.1\).

Pages 1 - - 23 - 24 - 25 - 26 - 27 - 28 - 29 - 30 - 31 - 32 - 33|||


MIL-DTL-45360H(AT)
22
1
1
0.5
17.13
1.38
1.38
1.38
7
0.38 DIA
5
8 holes thru
27.75
5
Laminate with nails
29.25
0.63 DIA
5
3 holes thru
0.5
0.56
1.5
24
4.88
10
46.75
48
ITEM 5 SHOWN
ITEM 6 OPPOSITE
SHEET 3 OF 3
NOTES:
1. Material: plywood, A-A-55057, type A, std. int. with ext. glue.
2. Dimensions are in inches.
3. Tolerance unless otherwise specified + 1/16.
FIGURE 5b. Saddle BII stowage.
