MIL-DTL-62013E(AT)
TABLE II. Classification of inspections - Continued.
First
Conformance
Title
Requirement
Inspection
article
tests
Turning
3.5.11
4.5.27
X
X
Shallow water crossing
3.5.12.1
4.5.28
X
X
Amphibious operation (M730A1)
3.5.12.2
4.5.29
X
Trench crossing
3.5.13
4.5.30
X
Vertical obstacle
3.5.14
4.5.31
X
Grade and slope operation
3.5.15
4.5.32
X
Suspension
3.5.16
4.5.33
X
Winch
3.5.17
4.5.34
X
Winch operation
3.5.17.1
4.5.34.1
X
X
Winch structural integrity
3.5.17.2
4.5.34.2
X
Winch controls
3.5.17.3
4.5.34.3
X
X
Noise level
3.9
4.5.35
X
Fire extinguisher
3.10
4.5.36
X
1/ To be performed with vehicle unloaded.
4.3 Conformance inspection. Conformance inspection shall include the examinations of
4.4 (see table I) and the tests of 4.5.5, 4.5.6.9 through 4.5.8.1, 4.5.10 through 4.5.12.3, 4.5.13,
4.5.14, 4.5.22 through 4.5.28, and 4.5.34 (see table II). Prior to the inspection, the break-in shall
be run (see 3.4). Following the examinations and prior to the tests, the vehicle shall be operated
for a distance of eight miles. Expect for equipment and component installation, and servicing
performed by the contractor as a final processing of vehicles for acceptance, vehicles shall be
completely assembled and serviced with fuel, lubricants, and fluids as specified. Vehicles need not
be loaded with rated payload except for holding test and amphibious operation as specified in
4.5.26 and 4.5.29.
4.4 Examination.
4.4.1 Sampling. Samples from an inspection lot for conformance inspection shall be
selected in accordance with ANSI Z1.4. Any redesign or modification of the contractor's
standard to comply with specified requirements shall receive particular attention for adequacy and
suitability. This element of inspection shall encompass all visual examinations and dimensional
measurements of requirements of 3.3, 3.3.1, 3.6, 3.7 and 3.8, as listed in table I. Noncompliance
with any specified requirement or presence of one or more defects preventing or lessening
maximum efficiency shall constitute cause for rejection.
18
