MIL-C-62326B
*
3.2.2 Sound level. The vehicle interior sound level shall conform to the requirements of
MIL-STD-1474, table 2, category D (less than 85 dB(A)).
*
3.2.3 Curb weight. The curb weight shall include the weight of the chassis and cab, with
all attachments, accessories, and equipment (whether standard or manufacturer's option); the
body; and a full complement of fuel, lubricants and coolant.
*
3.2.4 Payload. The payload shall be only the weight of the driver, passengers and cargo
being transported. No part of the vehicle shall be included in the payload weight.
*
3.2.5 Vehicle weights and dimensions. Vehicle weights and dimensions shall be as
specified in table I.
TABLE I. Weights and dimensions.
Feature
Type I
Type II
Type III
Weights
Vehicle gross weight (nominal, pounds)
7,400
7,400
7,400
Vehicle curb weight (empty)
(nominal, pounds)
5,000
5,600
5,300
Payload (minimum, pounds)
2,400
1,800
2,100
Ground pressure (at zero penetration)
(1) At curb weight (maximum,
pounds per square inch)
.79
.88
.84
(2) Loaded (maximum,
pounds per square inch)
1.17
1.17
1.17
Dimensions:
Overall length (nominal, inches)
144
154
144
Overall width (maximum, inches)
98
98
98
Height (without lights) (maximum, inches)
84
84
84
Ground clearance (minimum, inches)
9
9
9
Ground clearance with drop box guards
(minimum, inches)
7
7
7
Track width (minimum, inches)
36
36
36
Track footprint area (at zero
penetration) (minimum square inches)
6400
6400
6400
*
3.2.6 Accessibility. The design of the vehicle and optional equipment shall permit
access for routine servicing and shall permit access for replacement and adjustment of
component parts and accessories with minimal disturbance of other components and systems.
5
